【強化学習】UnityでML-Agentsを使ったCartPole学習（後半）

概要

手順

1. 学習のためのスクリプトを記述
2. 作成したモデルとスクリプトを紐づけ
3. 学習の実行

学習のためのスクリプトを記述

using UnityEngine;
using Unity.MLAgents;
using Unity.MLAgents.Sensors;
using Unity.MLAgents.Actuators;
using System.Collections;
using System.Collections.Generic;

public class CartPoleAgent : Agent
{

    public GameObject pole;
    Rigidbody poleRB;
    Rigidbody cartRB;
    EnvironmentParameters m_ResetParams;

    public override void Initialize()
    {
        poleRB = pole.GetComponent<Rigidbody>();
        cartRB = gameObject.GetComponent<Rigidbody>();
        m_ResetParams = Academy.Instance.EnvironmentParameters;
        SetResetParameters();
    }

    public override void CollectObservations(VectorSensor sensor)
    {
        sensor.AddObservation(gameObject.transform.localPosition.z);
        sensor.AddObservation(cartRB.velocity.z);
        sensor.AddObservation(pole.transform.localRotation.eulerAngles.x);
        sensor.AddObservation(poleRB.angularVelocity.x);
    }

    public override void OnActionReceived(ActionBuffers actionBuffers)
    {
        Vector3 controlSignal = Vector3.zero;
        controlSignal.x = actionBuffers.ContinuousActions[0];
        controlSignal.z = actionBuffers.ContinuousActions[1];
        var actionZ = 200f * Mathf.Clamp(actionBuffers.ContinuousActions[1], -1f, 1f);
        cartRB.AddForce(new Vector3(0.0f, 0.0f, actionZ), ForceMode.Force);

        float cart_z = this.gameObject.transform.localPosition.z;
        float angle_x = pole.transform.localRotation.eulerAngles.x;

        if(180f < angle_x && angle_x < 360f)
        {
            angle_x = angle_x - 360f;
        }

        if((-180f < angle_x && angle_x < -45f) || (45f < angle_x && angle_x < 180f))
        {
            SetReward(-1.0f);
            EndEpisode();
        }
        else{
            SetReward(0.1f);
        }

        if(cart_z < -10f || 10f < cart_z)
        {
            SetReward(-1.0f);
            EndEpisode();
        }
    }
    public override void OnActionReceived(float[] verctorAction)
    {
        var actionZ = 200f * Mathf.Clamp(verctorAction[0], -1f, 1f);
        cartRB.AddForce(new Vector3(0.0f, 0.0f, actionZ), ForceMode.Force);

        float cart_z = this.gameObject.transform.localPosition.z;
        float angle_x = pole.transform.localRotation.eulerAngles.x;

        if(180f < angle_x && angle_x < 360f)
        {
            angle_x = angle_x - 360f;
        }

        if((-180f < angle_x && angle_x < -45f) || (45f < angle_x && angle_x < 180f))
        {
            SetReward(-1.0f);
            EndEpisode();
        }
        else{
            SetReward(0.1f);
        }

        if(cart_z < -10f || 10f < cart_z)
        {
            SetReward(-1.0f);
            EndEpisode();
        }
    }

    public override void OnEpisodeBegin()
    {
        gameObject.transform.localPosition = new Vector3(0f, 0f, 0f);
        pole.transform.localPosition = new Vector3(0f, 2.5f, 0f);
        pole.transform.localRotation = Quaternion.Euler(0f, 0f, 0f);
        poleRB.angularVelocity = new Vector3(0f, 0f, 0f);
        poleRB.velocity = new Vector3(0f, 0f, 0f);

        poleRB.angularVelocity = new Vector3(Random.Range(-0.1f, 0.1f), 0f, 0f);
        SetResetParameters();
    }


    public void SetPole()
    {
        poleRB.mass = m_ResetParams.GetWithDefault("mass", 1.0f);
        pole.transform.localScale = new Vector3(0.4f, 2f, 0.4f);
    }

    public void SetResetParameters()
    {
        SetPole();
    }
}

public override void Initialize()

public override void CollectObservations(VectorSensor sensor)

• カートの位置
• カートの速度
• 棒の角度
• 棒の角速度

public override void OnActionReceived(ActionBuffers actionBuffers)

public override void OnEpisodeBegin()

作成したモデルとエージェントの紐付け

各パラメータは以下のように設定してください．

学習の実行

behaviors:
  CartPole:
    trainer_type: ppo
    hyperparameters:
      batch_size: 32
      buffer_size: 12000
      learning_rate: 0.0003
      beta: 0.001
      epsilon: 0.2
      lambd: 0.99
      num_epoch: 3
      learning_rate_schedule: linear
    network_settings:
      normalize: true
      hidden_units: 128
      num_layers: 2
      vis_encode_type: simple
    reward_signals:
      extrinsic:
        gamma: 0.99
        strength: 1.0
    keep_checkpoints: 5
    max_steps: 200000
    time_horizon: 1000
    summary_freq: 12000

mlagents-learn ../config/ppo/2D_cartpole.yaml  --run-id=2Dcartpole --train

無事に実行できると以下のような画面が表示されます．
