02.03 Computation on arrays ufuncs

https://picsum.photos/seed/bff74fa3affb442499195c1ba1f4fd9e/1200/630
Up until now, we have been discussing some of the basic nuts and bolts of NumPy; in the next few sections, we will dive into the reasons that NumPy is so important in the Python data science world. Namely, it provides an easy and flexible interface to optimized computation with arrays of data.
Computation on NumPy arrays can be very fast, or it can be very slow. The key to making it fast is to use vectorized operations, generally implemented through NumPy's universal functions (ufuncs). This section motivates the need for NumPy's ufuncs, which can be used to make repeated calculations on array elements much more efficient. It then introduces many of the most common and useful arithmetic ufuncs available in the NumPy package.

The Slowness of Loops

Python's default implementation (known as CPython) does some operations very slowly. This is in part due to the dynamic, interpreted nature of the language: the fact that types are flexible, so that sequences of operations cannot be compiled down to efficient machine code as in languages like C and Fortran. Recently there have been various attempts to address this weakness: well-known examples are the PyPy project, a just-in-time compiled implementation of Python; the Cython project, which converts Python code to compilable C code; and the Numba project, which converts snippets of Python code to fast LLVM bytecode. Each of these has its strengths and weaknesses, but it is safe to say that none of the three approaches has yet surpassed the reach and popularity of the standard CPython engine.
The relative sluggishness of Python generally manifests itself in situations where many small operations are being repeated – for instance looping over arrays to operate on each element. For example, imagine we have an array of values and we'd like to compute the reciprocal of each. A straightforward approach might look like this:
python
import numpy as np
np.random.seed(0)

def compute_reciprocals(values):
    output = np.empty(len(values))
    for i in range(len(values)):
        output[i] = 1.0 / values[i]
    return output

values = np.random.randint(1, 10, size=5)
compute_reciprocals(values)
array([ 0.16666667, 1. , 0.25 , 0.25 , 0.125 ])
This implementation probably feels fairly natural to someone from, say, a C or Java background. But if we measure the execution time of this code for a large input, we see that this operation is very slow, perhaps surprisingly so! We'll benchmark this with IPython's %timeit magic (discussed in Profiling and Timing Code):
python
big_array = np.random.randint(1, 100, size=1000000)
%timeit compute_reciprocals(big_array)
1 loop, best of 3: 2.91 s per loop
It takes several seconds to compute these million operations and to store the result! When even cell phones have processing speeds measured in Giga-FLOPS (i.e., billions of numerical operations per second), this seems almost absurdly slow. It turns out that the bottleneck here is not the operations themselves, but the type-checking and function dispatches that CPython must do at each cycle of the loop. Each time the reciprocal is computed, Python first examines the object's type and does a dynamic lookup of the correct function to use for that type. If we were working in compiled code instead, this type specification would be known before the code executes and the result could be computed much more efficiently.

Introducing UFuncs

For many types of operations, NumPy provides a convenient interface into just this kind of statically typed, compiled routine. This is known as a vectorized operation. This can be accomplished by simply performing an operation on the array, which will then be applied to each element. This vectorized approach is designed to push the loop into the compiled layer that underlies NumPy, leading to much faster execution.
Compare the results of the following two:
python
print(compute_reciprocals(values))
print(1.0 / values)
[ 0.16666667 1. 0.25 0.25 0.125 ] [ 0.16666667 1. 0.25 0.25 0.125 ]
Looking at the execution time for our big array, we see that it completes orders of magnitude faster than the Python loop:
python
%timeit (1.0 / big_array)
100 loops, best of 3: 4.6 ms per loop
Vectorized operations in NumPy are implemented via ufuncs, whose main purpose is to quickly execute repeated operations on values in NumPy arrays. Ufuncs are extremely flexible – before we saw an operation between a scalar and an array, but we can also operate between two arrays:
python
np.arange(5) / np.arange(1, 6)
array([ 0. , 0.5 , 0.66666667, 0.75 , 0.8 ])
And ufunc operations are not limited to one-dimensional arrays–they can also act on multi-dimensional arrays as well:
python
x = np.arange(9).reshape((3, 3))
2 ** x
array([[ 1, 2, 4], [ 8, 16, 32], [ 64, 128, 256]])
Computations using vectorization through ufuncs are nearly always more efficient than their counterpart implemented using Python loops, especially as the arrays grow in size. Any time you see such a loop in a Python script, you should consider whether it can be replaced with a vectorized expression.

Exploring NumPy's UFuncs

Ufuncs exist in two flavors: unary ufuncs, which operate on a single input, and binary ufuncs, which operate on two inputs. We'll see examples of both these types of functions here.

Array arithmetic

NumPy's ufuncs feel very natural to use because they make use of Python's native arithmetic operators. The standard addition, subtraction, multiplication, and division can all be used:
python
x = np.arange(4)
print("x     =", x)
print("x + 5 =", x + 5)
print("x - 5 =", x - 5)
print("x * 2 =", x * 2)
print("x / 2 =", x / 2)
print("x // 2 =", x // 2)  # floor division
x = [0 1 2 3] x + 5 = [5 6 7 8] x - 5 = [-5 -4 -3 -2] x * 2 = [0 2 4 6] x / 2 = [ 0. 0.5 1. 1.5] x // 2 = [0 0 1 1]
There is also a unary ufunc for negation, and a ** operator for exponentiation, and a % operator for modulus:
python
print("-x     = ", -x)
print("x ** 2 = ", x ** 2)
print("x % 2  = ", x % 2)
-x = [ 0 -1 -2 -3] x ** 2 = [0 1 4 9] x % 2 = [0 1 0 1]
In addition, these can be strung together however you wish, and the standard order of operations is respected:
python
-(0.5*x + 1) ** 2
array([-1. , -2.25, -4. , -6.25])
Each of these arithmetic operations are simply convenient wrappers around specific functions built into NumPy; for example, the + operator is a wrapper for the add function:
python
np.add(x, 2)
array([2, 3, 4, 5])
The following table lists the arithmetic operators implemented in NumPy:
OperatorEquivalent ufuncDescription
+np.addAddition (e.g., 1 + 1 = 2)
-np.subtractSubtraction (e.g., 3 - 2 = 1)
-np.negativeUnary negation (e.g., -2)
*np.multiplyMultiplication (e.g., 2 * 3 = 6)
/np.divideDivision (e.g., 3 / 2 = 1.5)
//np.floor_divideFloor division (e.g., 3 // 2 = 1)
**np.powerExponentiation (e.g., 2 ** 3 = 8)
%np.modModulus/remainder (e.g., 9 % 4 = 1)
Additionally there are Boolean/bitwise operators; we will explore these in Comparisons, Masks, and Boolean Logic.

Absolute value

Just as NumPy understands Python's built-in arithmetic operators, it also understands Python's built-in absolute value function:
python
x = np.array([-2, -1, 0, 1, 2])
abs(x)
array([2, 1, 0, 1, 2])
The corresponding NumPy ufunc is np.absolute, which is also available under the alias np.abs:
python
np.absolute(x)
array([2, 1, 0, 1, 2])
python
np.abs(x)
array([2, 1, 0, 1, 2])
This ufunc can also handle complex data, in which the absolute value returns the magnitude:
python
x = np.array([3 - 4j, 4 - 3j, 2 + 0j, 0 + 1j])
np.abs(x)
array([ 5., 5., 2., 1.])

Trigonometric functions

NumPy provides a large number of useful ufuncs, and some of the most useful for the data scientist are the trigonometric functions. We'll start by defining an array of angles:
python
theta = np.linspace(0, np.pi, 3)
Now we can compute some trigonometric functions on these values:
python
print("theta      = ", theta)
print("sin(theta) = ", np.sin(theta))
print("cos(theta) = ", np.cos(theta))
print("tan(theta) = ", np.tan(theta))
theta = [ 0. 1.57079633 3.14159265] sin(theta) = [ 0.00000000e+00 1.00000000e+00 1.22464680e-16] cos(theta) = [ 1.00000000e+00 6.12323400e-17 -1.00000000e+00] tan(theta) = [ 0.00000000e+00 1.63312394e+16 -1.22464680e-16]
The values are computed to within machine precision, which is why values that should be zero do not always hit exactly zero. Inverse trigonometric functions are also available:
python
x = [-1, 0, 1]
print("x         = ", x)
print("arcsin(x) = ", np.arcsin(x))
print("arccos(x) = ", np.arccos(x))
print("arctan(x) = ", np.arctan(x))
x = [-1, 0, 1] arcsin(x) = [-1.57079633 0. 1.57079633] arccos(x) = [ 3.14159265 1.57079633 0. ] arctan(x) = [-0.78539816 0. 0.78539816]

Exponents and logarithms

Another common type of operation available in a NumPy ufunc are the exponentials:
python
x = [1, 2, 3]
print("x     =", x)
print("e^x   =", np.exp(x))
print("2^x   =", np.exp2(x))
print("3^x   =", np.power(3, x))
x = [1, 2, 3] e^x = [ 2.71828183 7.3890561 20.08553692] 2^x = [ 2. 4. 8.] 3^x = [ 3 9 27]
The inverse of the exponentials, the logarithms, are also available. The basic np.log gives the natural logarithm; if you prefer to compute the base-2 logarithm or the base-10 logarithm, these are available as well:
python
x = [1, 2, 4, 10]
print("x        =", x)
print("ln(x)    =", np.log(x))
print("log2(x)  =", np.log2(x))
print("log10(x) =", np.log10(x))
x = [1, 2, 4, 10] ln(x) = [ 0. 0.69314718 1.38629436 2.30258509] log2(x) = [ 0. 1. 2. 3.32192809] log10(x) = [ 0. 0.30103 0.60205999 1. ]
There are also some specialized versions that are useful for maintaining precision with very small input:
python
x = [0, 0.001, 0.01, 0.1]
print("exp(x) - 1 =", np.expm1(x))
print("log(1 + x) =", np.log1p(x))
exp(x) - 1 = [ 0. 0.0010005 0.01005017 0.10517092] log(1 + x) = [ 0. 0.0009995 0.00995033 0.09531018]
When x is very small, these functions give more precise values than if the raw np.log or np.exp were to be used.

Specialized ufuncs

NumPy has many more ufuncs available, including hyperbolic trig functions, bitwise arithmetic, comparison operators, conversions from radians to degrees, rounding and remainders, and much more. A look through the NumPy documentation reveals a lot of interesting functionality.
Another excellent source for more specialized and obscure ufuncs is the submodule scipy.special. If you want to compute some obscure mathematical function on your data, chances are it is implemented in scipy.special. There are far too many functions to list them all, but the following snippet shows a couple that might come up in a statistics context:
python
from scipy import special
python
# Gamma functions (generalized factorials) and related functions
x = [1, 5, 10]
print("gamma(x)     =", special.gamma(x))
print("ln|gamma(x)| =", special.gammaln(x))
print("beta(x, 2)   =", special.beta(x, 2))
gamma(x) = [ 1.00000000e+00 2.40000000e+01 3.62880000e+05] ln|gamma(x)| = [ 0. 3.17805383 12.80182748] beta(x, 2) = [ 0.5 0.03333333 0.00909091]
python
# Error function (integral of Gaussian)
# its complement, and its inverse
x = np.array([0, 0.3, 0.7, 1.0])
print("erf(x)  =", special.erf(x))
print("erfc(x) =", special.erfc(x))
print("erfinv(x) =", special.erfinv(x))
erf(x) = [ 0. 0.32862676 0.67780119 0.84270079] erfc(x) = [ 1. 0.67137324 0.32219881 0.15729921] erfinv(x) = [ 0. 0.27246271 0.73286908 inf]
There are many, many more ufuncs available in both NumPy and scipy.special. Because the documentation of these packages is available online, a web search along the lines of "gamma function python" will generally find the relevant information.

Advanced Ufunc Features

Many NumPy users make use of ufuncs without ever learning their full set of features. We'll outline a few specialized features of ufuncs here.

Specifying output

For large calculations, it is sometimes useful to be able to specify the array where the result of the calculation will be stored. Rather than creating a temporary array, this can be used to write computation results directly to the memory location where you'd like them to be. For all ufuncs, this can be done using the out argument of the function:
python
x = np.arange(5)
y = np.empty(5)
np.multiply(x, 10, out=y)
print(y)
[ 0. 10. 20. 30. 40.]
This can even be used with array views. For example, we can write the results of a computation to every other element of a specified array:
python
y = np.zeros(10)
np.power(2, x, out=y[::2])
print(y)
[ 1. 0. 2. 0. 4. 0. 8. 0. 16. 0.]
If we had instead written y[::2] = 2 ** x, this would have resulted in the creation of a temporary array to hold the results of 2 ** x, followed by a second operation copying those values into the y array. This doesn't make much of a difference for such a small computation, but for very large arrays the memory savings from careful use of the out argument can be significant.

Aggregates

For binary ufuncs, there are some interesting aggregates that can be computed directly from the object. For example, if we'd like to reduce an array with a particular operation, we can use the reduce method of any ufunc. A reduce repeatedly applies a given operation to the elements of an array until only a single result remains.
For example, calling reduce on the add ufunc returns the sum of all elements in the array:
python
x = np.arange(1, 6)
np.add.reduce(x)
15
Similarly, calling reduce on the multiply ufunc results in the product of all array elements:
python
np.multiply.reduce(x)
120
If we'd like to store all the intermediate results of the computation, we can instead use accumulate:
python
np.add.accumulate(x)
array([ 1, 3, 6, 10, 15])
python
np.multiply.accumulate(x)
array([ 1, 2, 6, 24, 120])
Note that for these particular cases, there are dedicated NumPy functions to compute the results (np.sum, np.prod, np.cumsum, np.cumprod), which we'll explore in Aggregations: Min, Max, and Everything In Between.

Outer products

Finally, any ufunc can compute the output of all pairs of two different inputs using the outer method. This allows you, in one line, to do things like create a multiplication table:
python
x = np.arange(1, 6)
np.multiply.outer(x, x)
