06 Figure Code

https://picsum.photos/seed/201a4628b3b3433d9e21b4aa212233ba/1200/630
Many of the figures used throughout this text are created in-place by code that appears in print. In a few cases, however, the required code is long enough (or not immediately relevant enough) that we instead put it here for reference.
python
%matplotlib inline
import matplotlib.pyplot as plt
import numpy as np
import seaborn as sns
python
import os
if not os.path.exists('figures'):
    os.makedirs('figures')

Broadcasting

python
# Adapted from astroML: see http://www.astroml.org/book_figures/appendix/fig_broadcast_visual.html
import numpy as np
from matplotlib import pyplot as plt

#------------------------------------------------------------
# Draw a figure and axis with no boundary
fig = plt.figure(figsize=(6, 4.5), facecolor='w')
ax = plt.axes([0, 0, 1, 1], xticks=[], yticks=[], frameon=False)


def draw_cube(ax, xy, size, depth=0.4,
              edges=None, label=None, label_kwargs=None, **kwargs):
    """draw and label a cube.  edges is a list of numbers between
    1 and 12, specifying which of the 12 cube edges to draw"""
    if edges is None:
        edges = range(1, 13)

    x, y = xy

    if 1 in edges:
        ax.plot([x, x + size],
                [y + size, y + size], **kwargs)
    if 2 in edges:
        ax.plot([x + size, x + size],
                [y, y + size], **kwargs)
    if 3 in edges:
        ax.plot([x, x + size],
                [y, y], **kwargs)
    if 4 in edges:
        ax.plot([x, x],
                [y, y + size], **kwargs)

    if 5 in edges:
        ax.plot([x, x + depth],
                [y + size, y + depth + size], **kwargs)
    if 6 in edges:
        ax.plot([x + size, x + size + depth],
                [y + size, y + depth + size], **kwargs)
    if 7 in edges:
        ax.plot([x + size, x + size + depth],
                [y, y + depth], **kwargs)
    if 8 in edges:
        ax.plot([x, x + depth],
                [y, y + depth], **kwargs)

    if 9 in edges:
        ax.plot([x + depth, x + depth + size],
                [y + depth + size, y + depth + size], **kwargs)
    if 10 in edges:
        ax.plot([x + depth + size, x + depth + size],
                [y + depth, y + depth + size], **kwargs)
    if 11 in edges:
        ax.plot([x + depth, x + depth + size],
                [y + depth, y + depth], **kwargs)
    if 12 in edges:
        ax.plot([x + depth, x + depth],
                [y + depth, y + depth + size], **kwargs)

    if label:
        if label_kwargs is None:
            label_kwargs = {}
        ax.text(x + 0.5 * size, y + 0.5 * size, label,
                ha='center', va='center', **label_kwargs)

solid = dict(c='black', ls='-', lw=1,
             label_kwargs=dict(color='k'))
dotted = dict(c='black', ls='-', lw=0.5, alpha=0.5,
              label_kwargs=dict(color='gray'))
depth = 0.3

#------------------------------------------------------------
# Draw top operation: vector plus scalar
draw_cube(ax, (1, 10), 1, depth, [1, 2, 3, 4, 5, 6, 9], '0', **solid)
draw_cube(ax, (2, 10), 1, depth, [1, 2, 3, 6, 9], '1', **solid)
draw_cube(ax, (3, 10), 1, depth, [1, 2, 3, 6, 7, 9, 10], '2', **solid)

draw_cube(ax, (6, 10), 1, depth, [1, 2, 3, 4, 5, 6, 7, 9, 10], '5', **solid)
draw_cube(ax, (7, 10), 1, depth, [1, 2, 3, 6, 7, 9, 10, 11], '5', **dotted)
draw_cube(ax, (8, 10), 1, depth, [1, 2, 3, 6, 7, 9, 10, 11], '5', **dotted)

draw_cube(ax, (12, 10), 1, depth, [1, 2, 3, 4, 5, 6, 9], '5', **solid)
draw_cube(ax, (13, 10), 1, depth, [1, 2, 3, 6, 9], '6', **solid)
draw_cube(ax, (14, 10), 1, depth, [1, 2, 3, 6, 7, 9, 10], '7', **solid)

ax.text(5, 10.5, '+', size=12, ha='center', va='center')
ax.text(10.5, 10.5, '=', size=12, ha='center', va='center')
ax.text(1, 11.5, r'${\tt np.arange(3) + 5}$',
        size=12, ha='left', va='bottom')

#------------------------------------------------------------
# Draw middle operation: matrix plus vector

# first block
draw_cube(ax, (1, 7.5), 1, depth, [1, 2, 3, 4, 5, 6, 9], '1', **solid)
draw_cube(ax, (2, 7.5), 1, depth, [1, 2, 3, 6, 9], '1', **solid)
draw_cube(ax, (3, 7.5), 1, depth, [1, 2, 3, 6, 7, 9, 10], '1', **solid)

draw_cube(ax, (1, 6.5), 1, depth, [2, 3, 4], '1', **solid)
draw_cube(ax, (2, 6.5), 1, depth, [2, 3], '1', **solid)
draw_cube(ax, (3, 6.5), 1, depth, [2, 3, 7, 10], '1', **solid)

draw_cube(ax, (1, 5.5), 1, depth, [2, 3, 4], '1', **solid)
draw_cube(ax, (2, 5.5), 1, depth, [2, 3], '1', **solid)
draw_cube(ax, (3, 5.5), 1, depth, [2, 3, 7, 10], '1', **solid)

# second block
draw_cube(ax, (6, 7.5), 1, depth, [1, 2, 3, 4, 5, 6, 9], '0', **solid)
draw_cube(ax, (7, 7.5), 1, depth, [1, 2, 3, 6, 9], '1', **solid)
draw_cube(ax, (8, 7.5), 1, depth, [1, 2, 3, 6, 7, 9, 10], '2', **solid)

draw_cube(ax, (6, 6.5), 1, depth, range(2, 13), '0', **dotted)
draw_cube(ax, (7, 6.5), 1, depth, [2, 3, 6, 7, 9, 10, 11], '1', **dotted)
draw_cube(ax, (8, 6.5), 1, depth, [2, 3, 6, 7, 9, 10, 11], '2', **dotted)

draw_cube(ax, (6, 5.5), 1, depth, [2, 3, 4, 7, 8, 10, 11, 12], '0', **dotted)
draw_cube(ax, (7, 5.5), 1, depth, [2, 3, 7, 10, 11], '1', **dotted)
draw_cube(ax, (8, 5.5), 1, depth, [2, 3, 7, 10, 11], '2', **dotted)

# third block
draw_cube(ax, (12, 7.5), 1, depth, [1, 2, 3, 4, 5, 6, 9], '1', **solid)
draw_cube(ax, (13, 7.5), 1, depth, [1, 2, 3, 6, 9], '2', **solid)
draw_cube(ax, (14, 7.5), 1, depth, [1, 2, 3, 6, 7, 9, 10], '3', **solid)

draw_cube(ax, (12, 6.5), 1, depth, [2, 3, 4], '1', **solid)
draw_cube(ax, (13, 6.5), 1, depth, [2, 3], '2', **solid)
draw_cube(ax, (14, 6.5), 1, depth, [2, 3, 7, 10], '3', **solid)

draw_cube(ax, (12, 5.5), 1, depth, [2, 3, 4], '1', **solid)
draw_cube(ax, (13, 5.5), 1, depth, [2, 3], '2', **solid)
draw_cube(ax, (14, 5.5), 1, depth, [2, 3, 7, 10], '3', **solid)

ax.text(5, 7.0, '+', size=12, ha='center', va='center')
ax.text(10.5, 7.0, '=', size=12, ha='center', va='center')
ax.text(1, 9.0, r'${\tt np.ones((3,\, 3)) + np.arange(3)}$',
        size=12, ha='left', va='bottom')

#------------------------------------------------------------
# Draw bottom operation: vector plus vector, double broadcast

# first block
draw_cube(ax, (1, 3), 1, depth, [1, 2, 3, 4, 5, 6, 7, 9, 10], '0', **solid)
draw_cube(ax, (1, 2), 1, depth, [2, 3, 4, 7, 10], '1', **solid)
draw_cube(ax, (1, 1), 1, depth, [2, 3, 4, 7, 10], '2', **solid)

draw_cube(ax, (2, 3), 1, depth, [1, 2, 3, 6, 7, 9, 10, 11], '0', **dotted)
draw_cube(ax, (2, 2), 1, depth, [2, 3, 7, 10, 11], '1', **dotted)
draw_cube(ax, (2, 1), 1, depth, [2, 3, 7, 10, 11], '2', **dotted)

draw_cube(ax, (3, 3), 1, depth, [1, 2, 3, 6, 7, 9, 10, 11], '0', **dotted)
draw_cube(ax, (3, 2), 1, depth, [2, 3, 7, 10, 11], '1', **dotted)
draw_cube(ax, (3, 1), 1, depth, [2, 3, 7, 10, 11], '2', **dotted)

# second block
draw_cube(ax, (6, 3), 1, depth, [1, 2, 3, 4, 5, 6, 9], '0', **solid)
draw_cube(ax, (7, 3), 1, depth, [1, 2, 3, 6, 9], '1', **solid)
draw_cube(ax, (8, 3), 1, depth, [1, 2, 3, 6, 7, 9, 10], '2', **solid)

draw_cube(ax, (6, 2), 1, depth, range(2, 13), '0', **dotted)
draw_cube(ax, (7, 2), 1, depth, [2, 3, 6, 7, 9, 10, 11], '1', **dotted)
draw_cube(ax, (8, 2), 1, depth, [2, 3, 6, 7, 9, 10, 11], '2', **dotted)

draw_cube(ax, (6, 1), 1, depth, [2, 3, 4, 7, 8, 10, 11, 12], '0', **dotted)
draw_cube(ax, (7, 1), 1, depth, [2, 3, 7, 10, 11], '1', **dotted)
draw_cube(ax, (8, 1), 1, depth, [2, 3, 7, 10, 11], '2', **dotted)

# third block
draw_cube(ax, (12, 3), 1, depth, [1, 2, 3, 4, 5, 6, 9], '0', **solid)
draw_cube(ax, (13, 3), 1, depth, [1, 2, 3, 6, 9], '1', **solid)
draw_cube(ax, (14, 3), 1, depth, [1, 2, 3, 6, 7, 9, 10], '2', **solid)

draw_cube(ax, (12, 2), 1, depth, [2, 3, 4], '1', **solid)
draw_cube(ax, (13, 2), 1, depth, [2, 3], '2', **solid)
draw_cube(ax, (14, 2), 1, depth, [2, 3, 7, 10], '3', **solid)

draw_cube(ax, (12, 1), 1, depth, [2, 3, 4], '2', **solid)
draw_cube(ax, (13, 1), 1, depth, [2, 3], '3', **solid)
draw_cube(ax, (14, 1), 1, depth, [2, 3, 7, 10], '4', **solid)

ax.text(5, 2.5, '+', size=12, ha='center', va='center')
ax.text(10.5, 2.5, '=', size=12, ha='center', va='center')
ax.text(1, 4.5, r'${\tt np.arange(3).reshape((3,\, 1)) + np.arange(3)}$',
        ha='left', size=12, va='bottom')

ax.set_xlim(0, 16)
ax.set_ylim(0.5, 12.5)

fig.savefig('figures/02.05-broadcasting.png')
png

Aggregation and Grouping

Figures from the chapter on aggregation and grouping

Split-Apply-Combine

python
def draw_dataframe(df, loc=None, width=None, ax=None, linestyle=None,
                   textstyle=None):
    loc = loc or [0, 0]
    width = width or 1

    x, y = loc

    if ax is None:
        ax = plt.gca()

    ncols = len(df.columns) + 1
    nrows = len(df.index) + 1

    dx = dy = width / ncols

    if linestyle is None:
        linestyle = {'color':'black'}

    if textstyle is None:
        textstyle = {'size': 12}

    textstyle.update({'ha':'center', 'va':'center'})

    # draw vertical lines
    for i in range(ncols + 1):
        plt.plot(2 * [x + i * dx], [y, y + dy * nrows], **linestyle)

    # draw horizontal lines
    for i in range(nrows + 1):
        plt.plot([x, x + dx * ncols], 2 * [y + i * dy], **linestyle)

    # Create index labels
    for i in range(nrows - 1):
        plt.text(x + 0.5 * dx, y + (i + 0.5) * dy,
                 str(df.index[::-1][i]), **textstyle)

    # Create column labels
    for i in range(ncols - 1):
        plt.text(x + (i + 1.5) * dx, y + (nrows - 0.5) * dy,
                 str(df.columns[i]), style='italic', **textstyle)

    # Add index label
    if df.index.name:
        plt.text(x + 0.5 * dx, y + (nrows - 0.5) * dy,
                 str(df.index.name), style='italic', **textstyle)

    # Insert data
    for i in range(nrows - 1):
        for j in range(ncols - 1):
            plt.text(x + (j + 1.5) * dx,
                     y + (i + 0.5) * dy,
                     str(df.values[::-1][i, j]), **textstyle)


#----------------------------------------------------------
# Draw figure

import pandas as pd
df = pd.DataFrame({'data': [1, 2, 3, 4, 5, 6]},
                   index=['A', 'B', 'C', 'A', 'B', 'C'])
df.index.name = 'key'


fig = plt.figure(figsize=(8, 6), facecolor='white')
ax = plt.axes([0, 0, 1, 1])

ax.axis('off')

draw_dataframe(df, [0, 0])

for y, ind in zip([3, 1, -1], 'ABC'):
    split = df[df.index == ind]
    draw_dataframe(split, [2, y])

    sum = pd.DataFrame(split.sum()).T
    sum.index = [ind]
    sum.index.name = 'key'
    sum.columns = ['data']
    draw_dataframe(sum, [4, y + 0.25])

result = df.groupby(df.index).sum()
draw_dataframe(result, [6, 0.75])

style = dict(fontsize=14, ha='center', weight='bold')
plt.text(0.5, 3.6, "Input", **style)
plt.text(2.5, 4.6, "Split", **style)
plt.text(4.5, 4.35, "Apply (sum)", **style)
plt.text(6.5, 2.85, "Combine", **style)

arrowprops = dict(facecolor='black', width=1, headwidth=6)
plt.annotate('', (1.8, 3.6), (1.2, 2.8), arrowprops=arrowprops)
plt.annotate('', (1.8, 1.75), (1.2, 1.75), arrowprops=arrowprops)
plt.annotate('', (1.8, -0.1), (1.2, 0.7), arrowprops=arrowprops)

plt.annotate('', (3.8, 3.8), (3.2, 3.8), arrowprops=arrowprops)
plt.annotate('', (3.8, 1.75), (3.2, 1.75), arrowprops=arrowprops)
plt.annotate('', (3.8, -0.3), (3.2, -0.3), arrowprops=arrowprops)

plt.annotate('', (5.8, 2.8), (5.2, 3.6), arrowprops=arrowprops)
plt.annotate('', (5.8, 1.75), (5.2, 1.75), arrowprops=arrowprops)
plt.annotate('', (5.8, 0.7), (5.2, -0.1), arrowprops=arrowprops)

plt.axis('equal')
plt.ylim(-1.5, 5);

fig.savefig('figures/03.08-split-apply-combine.png')
png

What Is Machine Learning?

python
# common plot formatting for below
def format_plot(ax, title):
    ax.xaxis.set_major_formatter(plt.NullFormatter())
    ax.yaxis.set_major_formatter(plt.NullFormatter())
    ax.set_xlabel('feature 1', color='gray')
    ax.set_ylabel('feature 2', color='gray')
    ax.set_title(title, color='gray')

Classification Example Figures

The following code generates the figures from the Classification section.
python
from sklearn.datasets.samples_generator import make_blobs
from sklearn.svm import SVC

# create 50 separable points
X, y = make_blobs(n_samples=50, centers=2,
                  random_state=0, cluster_std=0.60)

# fit the support vector classifier model
clf = SVC(kernel='linear')
clf.fit(X, y)

# create some new points to predict
X2, _ = make_blobs(n_samples=80, centers=2,
                   random_state=0, cluster_std=0.80)
X2 = X2[50:]

# predict the labels
y2 = clf.predict(X2)
Classification Example Figure 1
python
# plot the data
fig, ax = plt.subplots(figsize=(8, 6))
point_style = dict(cmap='Paired', s=50)
ax.scatter(X[:, 0], X[:, 1], c=y, **point_style)

# format plot
format_plot(ax, 'Input Data')
ax.axis([-1, 4, -2, 7])

fig.savefig('figures/05.01-classification-1.png')
png
Classification Example Figure 2
python
# Get contours describing the model
xx = np.linspace(-1, 4, 10)
yy = np.linspace(-2, 7, 10)
xy1, xy2 = np.meshgrid(xx, yy)
Z = np.array([clf.decision_function([t])
              for t in zip(xy1.flat, xy2.flat)]).reshape(xy1.shape)

# plot points and model
fig, ax = plt.subplots(figsize=(8, 6))
line_style = dict(levels = [-1.0, 0.0, 1.0],
                  linestyles = ['dashed', 'solid', 'dashed'],
                  colors = 'gray', linewidths=1)
ax.scatter(X[:, 0], X[:, 1], c=y, **point_style)
ax.contour(xy1, xy2, Z, **line_style)

# format plot
format_plot(ax, 'Model Learned from Input Data')
ax.axis([-1, 4, -2, 7])

fig.savefig('figures/05.01-classification-2.png')
png
Classification Example Figure 3
python
# plot the results
fig, ax = plt.subplots(1, 2, figsize=(16, 6))
fig.subplots_adjust(left=0.0625, right=0.95, wspace=0.1)

ax[0].scatter(X2[:, 0], X2[:, 1], c='gray', **point_style)
ax[0].axis([-1, 4, -2, 7])

ax[1].scatter(X2[:, 0], X2[:, 1], c=y2, **point_style)
ax[1].contour(xy1, xy2, Z, **line_style)
ax[1].axis([-1, 4, -2, 7])

format_plot(ax[0], 'Unknown Data')
format_plot(ax[1], 'Predicted Labels')

fig.savefig('figures/05.01-classification-3.png')
png

Regression Example Figures

The following code generates the figures from the regression section.
python
from sklearn.linear_model import LinearRegression

# Create some data for the regression
rng = np.random.RandomState(1)

X = rng.randn(200, 2)
y = np.dot(X, [-2, 1]) + 0.1 * rng.randn(X.shape[0])

# fit the regression model
model = LinearRegression()
model.fit(X, y)

# create some new points to predict
X2 = rng.randn(100, 2)

# predict the labels
y2 = model.predict(X2)
Regression Example Figure 1
python
# plot data points
fig, ax = plt.subplots()
points = ax.scatter(X[:, 0], X[:, 1], c=y, s=50,
                    cmap='viridis')

# format plot
format_plot(ax, 'Input Data')
ax.axis([-4, 4, -3, 3])

fig.savefig('figures/05.01-regression-1.png')
png
Regression Example Figure 2
python
from mpl_toolkits.mplot3d.art3d import Line3DCollection

points = np.hstack([X, y[:, None]]).reshape(-1, 1, 3)
segments = np.hstack([points, points])
segments[:, 0, 2] = -8

# plot points in 3D
fig = plt.figure()
ax = fig.add_subplot(111, projection='3d')
ax.scatter(X[:, 0], X[:, 1], y, c=y, s=35,
           cmap='viridis')
ax.add_collection3d(Line3DCollection(segments, colors='gray', alpha=0.2))
ax.scatter(X[:, 0], X[:, 1], -8 + np.zeros(X.shape[0]), c=y, s=10,
           cmap='viridis')

# format plot
ax.patch.set_facecolor('white')
ax.view_init(elev=20, azim=-70)
ax.set_zlim3d(-8, 8)
ax.xaxis.set_major_formatter(plt.NullFormatter())
ax.yaxis.set_major_formatter(plt.NullFormatter())
ax.zaxis.set_major_formatter(plt.NullFormatter())
ax.set(xlabel='feature 1', ylabel='feature 2', zlabel='label')

# Hide axes (is there a better way?)
ax.w_xaxis.line.set_visible(False)
ax.w_yaxis.line.set_visible(False)
ax.w_zaxis.line.set_visible(False)
for tick in ax.w_xaxis.get_ticklines():
    tick.set_visible(False)
for tick in ax.w_yaxis.get_ticklines():
    tick.set_visible(False)
for tick in ax.w_zaxis.get_ticklines():
    tick.set_visible(False)

fig.savefig('figures/05.01-regression-2.png')
png
Regression Example Figure 3
python
from matplotlib.collections import LineCollection

# plot data points
fig, ax = plt.subplots()
pts = ax.scatter(X[:, 0], X[:, 1], c=y, s=50,
                 cmap='viridis', zorder=2)

# compute and plot model color mesh
xx, yy = np.meshgrid(np.linspace(-4, 4),
                     np.linspace(-3, 3))
Xfit = np.vstack([xx.ravel(), yy.ravel()]).T
yfit = model.predict(Xfit)
zz = yfit.reshape(xx.shape)
ax.pcolorfast([-4, 4], [-3, 3], zz, alpha=0.5,
              cmap='viridis', norm=pts.norm, zorder=1)

# format plot
format_plot(ax, 'Input Data with Linear Fit')
ax.axis([-4, 4, -3, 3])

fig.savefig('figures/05.01-regression-3.png')
png
Regression Example Figure 4
python
# plot the model fit
fig, ax = plt.subplots(1, 2, figsize=(16, 6))
fig.subplots_adjust(left=0.0625, right=0.95, wspace=0.1)

ax[0].scatter(X2[:, 0], X2[:, 1], c='gray', s=50)
ax[0].axis([-4, 4, -3, 3])

ax[1].scatter(X2[:, 0], X2[:, 1], c=y2, s=50,
              cmap='viridis', norm=pts.norm)
ax[1].axis([-4, 4, -3, 3])

# format plots
format_plot(ax[0], 'Unknown Data')
format_plot(ax[1], 'Predicted Labels')

fig.savefig('figures/05.01-regression-4.png')
png

Clustering Example Figures

The following code generates the figures from the clustering section.
python
from sklearn.datasets.samples_generator import make_blobs
from sklearn.cluster import KMeans

# create 50 separable points
X, y = make_blobs(n_samples=100, centers=4,
                  random_state=42, cluster_std=1.5)

# Fit the K Means model
model = KMeans(4, random_state=0)
y = model.fit_predict(X)
Clustering Example Figure 1
python
# plot the input data
fig, ax = plt.subplots(figsize=(8, 6))
ax.scatter(X[:, 0], X[:, 1], s=50, color='gray')

# format the plot
format_plot(ax, 'Input Data')

fig.savefig('figures/05.01-clustering-1.png')
png
Clustering Example Figure 2
python
# plot the data with cluster labels
fig, ax = plt.subplots(figsize=(8, 6))
ax.scatter(X[:, 0], X[:, 1], s=50, c=y, cmap='viridis')

# format the plot
format_plot(ax, 'Learned Cluster Labels')

fig.savefig('figures/05.01-clustering-2.png')
png

Dimensionality Reduction Example Figures

The following code generates the figures from the dimensionality reduction section.
Dimensionality Reduction Example Figure 1
python
from sklearn.datasets import make_swiss_roll

# make data
X, y = make_swiss_roll(200, noise=0.5, random_state=42)
X = X[:, [0, 2]]

# visualize data
fig, ax = plt.subplots()
ax.scatter(X[:, 0], X[:, 1], color='gray', s=30)

# format the plot
format_plot(ax, 'Input Data')

fig.savefig('figures/05.01-dimesionality-1.png')
png
Dimensionality Reduction Example Figure 2
python
from sklearn.manifold import Isomap

model = Isomap(n_neighbors=8, n_components=1)
y_fit = model.fit_transform(X).ravel()

# visualize data
fig, ax = plt.subplots()
pts = ax.scatter(X[:, 0], X[:, 1], c=y_fit, cmap='viridis', s=30)
cb = fig.colorbar(pts, ax=ax)

# format the plot
format_plot(ax, 'Learned Latent Parameter')
cb.set_ticks([])
cb.set_label('Latent Variable', color='gray')

fig.savefig('figures/05.01-dimesionality-2.png')
png

Introducing Scikit-Learn

Features and Labels Grid

The following is the code generating the diagram showing the features matrix and target array.
python
fig = plt.figure(figsize=(6, 4))
ax = fig.add_axes([0, 0, 1, 1])
ax.axis('off')
ax.axis('equal')

# Draw features matrix
ax.vlines(range(6), ymin=0, ymax=9, lw=1)
ax.hlines(range(10), xmin=0, xmax=5, lw=1)
font_prop = dict(size=12, family='monospace')
ax.text(-1, -1, "Feature Matrix ($X$)", size=14)
ax.text(0.1, -0.3, r'n_features $\longrightarrow$', **font_prop)
ax.text(-0.1, 0.1, r'$\longleftarrow$ n_samples', rotation=90,
        va='top', ha='right', **font_prop)

# Draw labels vector
ax.vlines(range(8, 10), ymin=0, ymax=9, lw=1)
ax.hlines(range(10), xmin=8, xmax=9, lw=1)
ax.text(7, -1, "Target Vector ($y$)", size=14)
ax.text(7.9, 0.1, r'$\longleftarrow$ n_samples', rotation=90,
        va='top', ha='right', **font_prop)

ax.set_ylim(10, -2)

fig.savefig('figures/05.02-samples-features.png')
png

Hyperparameters and Model Validation

Cross-Validation Figures

python
def draw_rects(N, ax, textprop={}):
    for i in range(N):
        ax.add_patch(plt.Rectangle((0, i), 5, 0.7, fc='white'))
        ax.add_patch(plt.Rectangle((5. * i / N, i), 5. / N, 0.7, fc='lightgray'))
        ax.text(5. * (i + 0.5) / N, i + 0.35,
                "validation\nset", ha='center', va='center', **textprop)
        ax.text(0, i + 0.35, "trial {0}".format(N - i),
                ha='right', va='center', rotation=90, **textprop)
    ax.set_xlim(-1, 6)
    ax.set_ylim(-0.2, N + 0.2)
2-Fold Cross-Validation
python
fig = plt.figure()
ax = fig.add_axes([0, 0, 1, 1])
ax.axis('off')
draw_rects(2, ax, textprop=dict(size=14))

fig.savefig('figures/05.03-2-fold-CV.png')
png
5-Fold Cross-Validation
python
fig = plt.figure()
ax = fig.add_axes([0, 0, 1, 1])
ax.axis('off')
draw_rects(5, ax, textprop=dict(size=10))

fig.savefig('figures/05.03-5-fold-CV.png')
png

Overfitting and Underfitting

python
import numpy as np

def make_data(N=30, err=0.8, rseed=1):
    # randomly sample the data
    rng = np.random.RandomState(rseed)
    X = rng.rand(N, 1) ** 2
    y = 10 - 1. / (X.ravel() + 0.1)
    if err > 0:
        y += err * rng.randn(N)
    return X, y
python
from sklearn.preprocessing import PolynomialFeatures
from sklearn.linear_model import LinearRegression
from sklearn.pipeline import make_pipeline

def PolynomialRegression(degree=2, **kwargs):
    return make_pipeline(PolynomialFeatures(degree),
                         LinearRegression(**kwargs))
Bias-Variance Tradeoff
python
X, y = make_data()
xfit = np.linspace(-0.1, 1.0, 1000)[:, None]
model1 = PolynomialRegression(1).fit(X, y)
model20 = PolynomialRegression(20).fit(X, y)

fig, ax = plt.subplots(1, 2, figsize=(16, 6))
fig.subplots_adjust(left=0.0625, right=0.95, wspace=0.1)

ax[0].scatter(X.ravel(), y, s=40)
ax[0].plot(xfit.ravel(), model1.predict(xfit), color='gray')
ax[0].axis([-0.1, 1.0, -2, 14])
ax[0].set_title('High-bias model: Underfits the data', size=14)

ax[1].scatter(X.ravel(), y, s=40)
ax[1].plot(xfit.ravel(), model20.predict(xfit), color='gray')
ax[1].axis([-0.1, 1.0, -2, 14])
ax[1].set_title('High-variance model: Overfits the data', size=14)

fig.savefig('figures/05.03-bias-variance.png')
png
Bias-Variance Tradeoff Metrics
python
fig, ax = plt.subplots(1, 2, figsize=(16, 6))
fig.subplots_adjust(left=0.0625, right=0.95, wspace=0.1)

X2, y2 = make_data(10, rseed=42)

ax[0].scatter(X.ravel(), y, s=40, c='blue')
ax[0].plot(xfit.ravel(), model1.predict(xfit), color='gray')
ax[0].axis([-0.1, 1.0, -2, 14])
ax[0].set_title('High-bias model: Underfits the data', size=14)
ax[0].scatter(X2.ravel(), y2, s=40, c='red')
ax[0].text(0.02, 0.98, "training score: $R^2$ = {0:.2f}".format(model1.score(X, y)),
           ha='left', va='top', transform=ax[0].transAxes, size=14, color='blue')
ax[0].text(0.02, 0.91, "validation score: $R^2$ = {0:.2f}".format(model1.score(X2, y2)),
           ha='left', va='top', transform=ax[0].transAxes, size=14, color='red')

ax[1].scatter(X.ravel(), y, s=40, c='blue')
ax[1].plot(xfit.ravel(), model20.predict(xfit), color='gray')
ax[1].axis([-0.1, 1.0, -2, 14])
ax[1].set_title('High-variance model: Overfits the data', size=14)
ax[1].scatter(X2.ravel(), y2, s=40, c='red')
ax[1].text(0.02, 0.98, "training score: $R^2$ = {0:.2g}".format(model20.score(X, y)),
           ha='left', va='top', transform=ax[1].transAxes, size=14, color='blue')
ax[1].text(0.02, 0.91, "validation score: $R^2$ = {0:.2g}".format(model20.score(X2, y2)),
           ha='left', va='top', transform=ax[1].transAxes, size=14, color='red')

fig.savefig('figures/05.03-bias-variance-2.png')
png
Validation Curve
python
x = np.linspace(0, 1, 1000)
y1 = -(x - 0.5) ** 2
y2 = y1 - 0.33 + np.exp(x - 1)

fig, ax = plt.subplots()
ax.plot(x, y2, lw=10, alpha=0.5, color='blue')
ax.plot(x, y1, lw=10, alpha=0.5, color='red')

ax.text(0.15, 0.2, "training score", rotation=45, size=16, color='blue')
ax.text(0.2, -0.05, "validation score", rotation=20, size=16, color='red')

ax.text(0.02, 0.1, r'$\longleftarrow$ High Bias', size=18, rotation=90, va='center')
ax.text(0.98, 0.1, r'$\longleftarrow$ High Variance $\longrightarrow$', size=18, rotation=90, ha='right', va='center')
ax.text(0.48, -0.12, 'Best$\\longrightarrow$\nModel', size=18, rotation=90, va='center')

ax.set_xlim(0, 1)
ax.set_ylim(-0.3, 0.5)

ax.set_xlabel(r'model complexity $\longrightarrow$', size=14)
ax.set_ylabel(r'model score $\longrightarrow$', size=14)

ax.xaxis.set_major_formatter(plt.NullFormatter())
ax.yaxis.set_major_formatter(plt.NullFormatter())

ax.set_title("Validation Curve Schematic", size=16)

fig.savefig('figures/05.03-validation-curve.png')
png
Learning Curve
python
N = np.linspace(0, 1, 1000)
y1 = 0.75 + 0.2 * np.exp(-4 * N)
y2 = 0.7 - 0.6 * np.exp(-4 * N)

fig, ax = plt.subplots()
ax.plot(x, y1, lw=10, alpha=0.5, color='blue')
ax.plot(x, y2, lw=10, alpha=0.5, color='red')

ax.text(0.2, 0.88, "training score", rotation=-10, size=16, color='blue')
ax.text(0.2, 0.5, "validation score", rotation=30, size=16, color='red')

ax.text(0.98, 0.45, r'Good Fit $\longrightarrow$', size=18, rotation=90, ha='right', va='center')
ax.text(0.02, 0.57, r'$\longleftarrow$ High Variance $\longrightarrow$', size=18, rotation=90, va='center')

ax.set_xlim(0, 1)
ax.set_ylim(0, 1)

ax.set_xlabel(r'training set size $\longrightarrow$', size=14)
ax.set_ylabel(r'model score $\longrightarrow$', size=14)

ax.xaxis.set_major_formatter(plt.NullFormatter())
ax.yaxis.set_major_formatter(plt.NullFormatter())

ax.set_title("Learning Curve Schematic", size=16)

fig.savefig('figures/05.03-learning-curve.png')
png

Gaussian Naive Bayes

Gaussian Naive Bayes Example

python
from sklearn.datasets import make_blobs
X, y = make_blobs(100, 2, centers=2, random_state=2, cluster_std=1.5)

fig, ax = plt.subplots()

ax.scatter(X[:, 0], X[:, 1], c=y, s=50, cmap='RdBu')
ax.set_title('Naive Bayes Model', size=14)

xlim = (-8, 8)
ylim = (-15, 5)

xg = np.linspace(xlim[0], xlim[1], 60)
yg = np.linspace(ylim[0], ylim[1], 40)
xx, yy = np.meshgrid(xg, yg)
Xgrid = np.vstack([xx.ravel(), yy.ravel()]).T

for label, color in enumerate(['red', 'blue']):
    mask = (y == label)
    mu, std = X[mask].mean(0), X[mask].std(0)
    P = np.exp(-0.5 * (Xgrid - mu) ** 2 / std ** 2).prod(1)
    Pm = np.ma.masked_array(P, P < 0.03)
    ax.pcolorfast(xg, yg, Pm.reshape(xx.shape), alpha=0.5,
                  cmap=color.title() + 's')
    ax.contour(xx, yy, P.reshape(xx.shape),
               levels=[0.01, 0.1, 0.5, 0.9],
               colors=color, alpha=0.2)

ax.set(xlim=xlim, ylim=ylim)

fig.savefig('figures/05.05-gaussian-NB.png')
png

Linear Regression

Gaussian Basis Functions

python
from sklearn.pipeline import make_pipeline
from sklearn.linear_model import LinearRegression

from sklearn.base import BaseEstimator, TransformerMixin

class GaussianFeatures(BaseEstimator, TransformerMixin):
    """Uniformly-spaced Gaussian Features for 1D input"""

    def __init__(self, N, width_factor=2.0):
        self.N = N
        self.width_factor = width_factor

    @staticmethod
    def _gauss_basis(x, y, width, axis=None):
        arg = (x - y) / width
        return np.exp(-0.5 * np.sum(arg ** 2, axis))

    def fit(self, X, y=None):
        # create N centers spread along the data range
        self.centers_ = np.linspace(X.min(), X.max(), self.N)
        self.width_ = self.width_factor * (self.centers_[1] - self.centers_[0])
        return self

    def transform(self, X):
        return self._gauss_basis(X[:, :, np.newaxis], self.centers_,
                                 self.width_, axis=1)

rng = np.random.RandomState(1)
x = 10 * rng.rand(50)
y = np.sin(x) + 0.1 * rng.randn(50)
xfit = np.linspace(0, 10, 1000)

gauss_model = make_pipeline(GaussianFeatures(10, 1.0),
                            LinearRegression())
gauss_model.fit(x[:, np.newaxis], y)
yfit = gauss_model.predict(xfit[:, np.newaxis])

gf = gauss_model.named_steps['gaussianfeatures']
lm = gauss_model.named_steps['linearregression']

fig, ax = plt.subplots()

for i in range(10):
    selector = np.zeros(10)
    selector[i] = 1
    Xfit = gf.transform(xfit[:, None]) * selector
    yfit = lm.predict(Xfit)
    ax.fill_between(xfit, yfit.min(), yfit, color='gray', alpha=0.2)

ax.scatter(x, y)
ax.plot(xfit, gauss_model.predict(xfit[:, np.newaxis]))
ax.set_xlim(0, 10)
ax.set_ylim(yfit.min(), 1.5)

fig.savefig('figures/05.06-gaussian-basis.png')
png

Random Forests

Helper Code

The following will create a module helpers_05_08.py which contains some tools used in In-Depth: Decision Trees and Random Forests.
python
%%file helpers_05_08.py

import numpy as np
import matplotlib.pyplot as plt
from sklearn.tree import DecisionTreeClassifier
from ipywidgets import interact


def visualize_tree(estimator, X, y, boundaries=True,
                   xlim=None, ylim=None, ax=None):
    ax = ax or plt.gca()

    # Plot the training points
    ax.scatter(X[:, 0], X[:, 1], c=y, s=30, cmap='viridis',
               clim=(y.min(), y.max()), zorder=3)
    ax.axis('tight')
    ax.axis('off')
    if xlim is None:
        xlim = ax.get_xlim()
    if ylim is None:
        ylim = ax.get_ylim()

    # fit the estimator
    estimator.fit(X, y)
    xx, yy = np.meshgrid(np.linspace(*xlim, num=200),
                         np.linspace(*ylim, num=200))
    Z = estimator.predict(np.c_[xx.ravel(), yy.ravel()])

    # Put the result into a color plot
    n_classes = len(np.unique(y))
    Z = Z.reshape(xx.shape)
    contours = ax.contourf(xx, yy, Z, alpha=0.3,
                           levels=np.arange(n_classes + 1) - 0.5,
                           cmap='viridis', clim=(y.min(), y.max()),
                           zorder=1)

    ax.set(xlim=xlim, ylim=ylim)

    # Plot the decision boundaries
    def plot_boundaries(i, xlim, ylim):
        if i >= 0:
            tree = estimator.tree_

            if tree.feature[i] == 0:
                ax.plot([tree.threshold[i], tree.threshold[i]], ylim, '-k', zorder=2)
                plot_boundaries(tree.children_left[i],
                                [xlim[0], tree.threshold[i]], ylim)
                plot_boundaries(tree.children_right[i],
                                [tree.threshold[i], xlim[1]], ylim)

            elif tree.feature[i] == 1:
                ax.plot(xlim, [tree.threshold[i], tree.threshold[i]], '-k', zorder=2)
                plot_boundaries(tree.children_left[i], xlim,
                                [ylim[0], tree.threshold[i]])
                plot_boundaries(tree.children_right[i], xlim,
                                [tree.threshold[i], ylim[1]])

    if boundaries:
        plot_boundaries(0, xlim, ylim)


def plot_tree_interactive(X, y):
    def interactive_tree(depth=5):
        clf = DecisionTreeClassifier(max_depth=depth, random_state=0)
        visualize_tree(clf, X, y)

    return interact(interactive_tree, depth=[1, 5])


def randomized_tree_interactive(X, y):
    N = int(0.75 * X.shape[0])

    xlim = (X[:, 0].min(), X[:, 0].max())
    ylim = (X[:, 1].min(), X[:, 1].max())

    def fit_randomized_tree(random_state=0):
        clf = DecisionTreeClassifier(max_depth=15)
        i = np.arange(len(y))
        rng = np.random.RandomState(random_state)
        rng.shuffle(i)
        visualize_tree(clf, X[i[:N]], y[i[:N]], boundaries=False,
                       xlim=xlim, ylim=ylim)

    interact(fit_randomized_tree, random_state=[0, 100]);
Overwriting helpers_05_08.py

Decision Tree Example

python
fig = plt.figure(figsize=(10, 4))
ax = fig.add_axes([0, 0, 0.8, 1], frameon=False, xticks=[], yticks=[])
ax.set_title('Example Decision Tree: Animal Classification', size=24)

def text(ax, x, y, t, size=20, **kwargs):
    ax.text(x, y, t,
            ha='center', va='center', size=size,
            bbox=dict(boxstyle='round', ec='k', fc='w'), **kwargs)

text(ax, 0.5, 0.9, "How big is\nthe animal?", 20)
text(ax, 0.3, 0.6, "Does the animal\nhave horns?", 18)
text(ax, 0.7, 0.6, "Does the animal\nhave two legs?", 18)
text(ax, 0.12, 0.3, "Are the horns\nlonger than 10cm?", 14)
text(ax, 0.38, 0.3, "Is the animal\nwearing a collar?", 14)
text(ax, 0.62, 0.3, "Does the animal\nhave wings?", 14)
text(ax, 0.88, 0.3, "Does the animal\nhave a tail?", 14)

text(ax, 0.4, 0.75, "> 1m", 12, alpha=0.4)
text(ax, 0.6, 0.75, "< 1m", 12, alpha=0.4)

text(ax, 0.21, 0.45, "yes", 12, alpha=0.4)
text(ax, 0.34, 0.45, "no", 12, alpha=0.4)

text(ax, 0.66, 0.45, "yes", 12, alpha=0.4)
text(ax, 0.79, 0.45, "no", 12, alpha=0.4)

ax.plot([0.3, 0.5, 0.7], [0.6, 0.9, 0.6], '-k')
ax.plot([0.12, 0.3, 0.38], [0.3, 0.6, 0.3], '-k')
ax.plot([0.62, 0.7, 0.88], [0.3, 0.6, 0.3], '-k')
ax.plot([0.0, 0.12, 0.20], [0.0, 0.3, 0.0], '--k')
ax.plot([0.28, 0.38, 0.48], [0.0, 0.3, 0.0], '--k')
ax.plot([0.52, 0.62, 0.72], [0.0, 0.3, 0.0], '--k')
ax.plot([0.8, 0.88, 1.0], [0.0, 0.3, 0.0], '--k')
ax.axis([0, 1, 0, 1])

fig.savefig('figures/05.08-decision-tree.png')
png

Decision Tree Levels

python
from helpers_05_08 import visualize_tree
from sklearn.tree import DecisionTreeClassifier
from sklearn.datasets import make_blobs


fig, ax = plt.subplots(1, 4, figsize=(16, 3))
fig.subplots_adjust(left=0.02, right=0.98, wspace=0.1)

X, y = make_blobs(n_samples=300, centers=4,
                  random_state=0, cluster_std=1.0)

for axi, depth in zip(ax, range(1, 5)):
    model = DecisionTreeClassifier(max_depth=depth)
    visualize_tree(model, X, y, ax=axi)
    axi.set_title('depth = {0}'.format(depth))

fig.savefig('figures/05.08-decision-tree-levels.png')
png

Decision Tree Overfitting

python
model = DecisionTreeClassifier()

fig, ax = plt.subplots(1, 2, figsize=(16, 6))
fig.subplots_adjust(left=0.0625, right=0.95, wspace=0.1)
visualize_tree(model, X[::2], y[::2], boundaries=False, ax=ax[0])
visualize_tree(model, X[1::2], y[1::2], boundaries=False, ax=ax[1])

fig.savefig('figures/05.08-decision-tree-overfitting.png')
png

Principal Component Analysis

Principal Components Rotation

python
from sklearn.decomposition import PCA
python
def draw_vector(v0, v1, ax=None):
    ax = ax or plt.gca()
    arrowprops=dict(arrowstyle='->',
                    linewidth=2,
                    shrinkA=0, shrinkB=0)
    ax.annotate('', v1, v0, arrowprops=arrowprops)
python
rng = np.random.RandomState(1)
X = np.dot(rng.rand(2, 2), rng.randn(2, 200)).T
pca = PCA(n_components=2, whiten=True)
pca.fit(X)

fig, ax = plt.subplots(1, 2, figsize=(16, 6))
fig.subplots_adjust(left=0.0625, right=0.95, wspace=0.1)

# plot data
ax[0].scatter(X[:, 0], X[:, 1], alpha=0.2)
for length, vector in zip(pca.explained_variance_, pca.components_):
    v = vector * 3 * np.sqrt(length)
    draw_vector(pca.mean_, pca.mean_ + v, ax=ax[0])
ax[0].axis('equal');
ax[0].set(xlabel='x', ylabel='y', title='input')

# plot principal components
X_pca = pca.transform(X)
ax[1].scatter(X_pca[:, 0], X_pca[:, 1], alpha=0.2)
draw_vector([0, 0], [0, 3], ax=ax[1])
draw_vector([0, 0], [3, 0], ax=ax[1])
ax[1].axis('equal')
ax[1].set(xlabel='component 1', ylabel='component 2',
          title='principal components',
          xlim=(-5, 5), ylim=(-3, 3.1))

fig.savefig('figures/05.09-PCA-rotation.png')
png

Digits Pixel Components

python
def plot_pca_components(x, coefficients=None, mean=0, components=None,
                        imshape=(8, 8), n_components=8, fontsize=12,
                        show_mean=True):
    if coefficients is None:
        coefficients = x

    if components is None:
        components = np.eye(len(coefficients), len(x))

    mean = np.zeros_like(x) + mean


    fig = plt.figure(figsize=(1.2 * (5 + n_components), 1.2 * 2))
    g = plt.GridSpec(2, 4 + bool(show_mean) + n_components, hspace=0.3)

    def show(i, j, x, title=None):
        ax = fig.add_subplot(g[i, j], xticks=[], yticks=[])
        ax.imshow(x.reshape(imshape), interpolation='nearest')
        if title:
            ax.set_title(title, fontsize=fontsize)

    show(slice(2), slice(2), x, "True")

    approx = mean.copy()

    counter = 2
    if show_mean:
        show(0, 2, np.zeros_like(x) + mean, r'$\mu$')
        show(1, 2, approx, r'$1 \cdot \mu$')
        counter += 1

    for i in range(n_components):
        approx = approx + coefficients[i] * components[i]
        show(0, i + counter, components[i], r'$c_{0}$'.format(i + 1))
        show(1, i + counter, approx,
             r"${0:.2f} \cdot c_{1}$".format(coefficients[i], i + 1))
        if show_mean or i > 0:
            plt.gca().text(0, 1.05, '$+$', ha='right', va='bottom',
                           transform=plt.gca().transAxes, fontsize=fontsize)

    show(slice(2), slice(-2, None), approx, "Approx")
    return fig
python
from sklearn.datasets import load_digits

digits = load_digits()
sns.set_style('white')

fig = plot_pca_components(digits.data[10],
                          show_mean=False)

fig.savefig('figures/05.09-digits-pixel-components.png')
png

Digits PCA Components

python
pca = PCA(n_components=8)
Xproj = pca.fit_transform(digits.data)
sns.set_style('white')
fig = plot_pca_components(digits.data[10], Xproj[10],
                          pca.mean_, pca.components_)

fig.savefig('figures/05.09-digits-pca-components.png')
png

Manifold Learning

LLE vs MDS Linkages

python
def make_hello(N=1000, rseed=42):
    # Make a plot with "HELLO" text; save as png
    fig, ax = plt.subplots(figsize=(4, 1))
    fig.subplots_adjust(left=0, right=1, bottom=0, top=1)
    ax.axis('off')
    ax.text(0.5, 0.4, 'HELLO', va='center', ha='center', weight='bold', size=85)
    fig.savefig('hello.png')
    plt.close(fig)

    # Open this PNG and draw random points from it
    from matplotlib.image import imread
    data = imread('hello.png')[::-1, :, 0].T
    rng = np.random.RandomState(rseed)
    X = rng.rand(4 * N, 2)
    i, j = (X * data.shape).astype(int).T
    mask = (data[i, j] < 1)
    X = X[mask]
    X[:, 0] *= (data.shape[0] / data.shape[1])
    X = X[:N]
    return X[np.argsort(X[:, 0])]
python
def make_hello_s_curve(X):
    t = (X[:, 0] - 2) * 0.75 * np.pi
    x = np.sin(t)
    y = X[:, 1]
    z = np.sign(t) * (np.cos(t) - 1)
    return np.vstack((x, y, z)).T

X = make_hello(1000)
XS = make_hello_s_curve(X)
colorize = dict(c=X[:, 0], cmap=plt.cm.get_cmap('rainbow', 5))
python
from mpl_toolkits.mplot3d.art3d import Line3DCollection
from sklearn.neighbors import NearestNeighbors

# construct lines for MDS
rng = np.random.RandomState(42)
ind = rng.permutation(len(X))
lines_MDS = [(XS[i], XS[j]) for i in ind[:100] for j in ind[100:200]]

# construct lines for LLE
nbrs = NearestNeighbors(n_neighbors=100).fit(XS).kneighbors(XS[ind[:100]])[1]
lines_LLE = [(XS[ind[i]], XS[j]) for i in range(100) for j in nbrs[i]]
titles = ['MDS Linkages', 'LLE Linkages (100 NN)']

# plot the results
fig, ax = plt.subplots(1, 2, figsize=(16, 6),
                       subplot_kw=dict(projection='3d', axisbg='none'))
fig.subplots_adjust(left=0, right=1, bottom=0, top=1, hspace=0, wspace=0)

for axi, title, lines in zip(ax, titles, [lines_MDS, lines_LLE]):
    axi.scatter3D(XS[:, 0], XS[:, 1], XS[:, 2], **colorize);
    axi.add_collection(Line3DCollection(lines, lw=1, color='black',
                                        alpha=0.05))
    axi.view_init(elev=10, azim=-80)
    axi.set_title(title, size=18)

fig.savefig('figures/05.10-LLE-vs-MDS.png')
png

K-Means

Expectation-Maximization

The following figure shows a visual depiction of the Expectation-Maximization approach to K Means:
python
from sklearn.datasets.samples_generator import make_blobs
from sklearn.metrics import pairwise_distances_argmin

X, y_true = make_blobs(n_samples=300, centers=4,
                       cluster_std=0.60, random_state=0)

rng = np.random.RandomState(42)
centers = [0, 4] + rng.randn(4, 2)

def draw_points(ax, c, factor=1):
    ax.scatter(X[:, 0], X[:, 1], c=c, cmap='viridis',
               s=50 * factor, alpha=0.3)

def draw_centers(ax, centers, factor=1, alpha=1.0):
    ax.scatter(centers[:, 0], centers[:, 1],
               c=np.arange(4), cmap='viridis', s=200 * factor,
               alpha=alpha)
    ax.scatter(centers[:, 0], centers[:, 1],
               c='black', s=50 * factor, alpha=alpha)

def make_ax(fig, gs):
    ax = fig.add_subplot(gs)
    ax.xaxis.set_major_formatter(plt.NullFormatter())
    ax.yaxis.set_major_formatter(plt.NullFormatter())
    return ax

fig = plt.figure(figsize=(15, 4))
gs = plt.GridSpec(4, 15, left=0.02, right=0.98, bottom=0.05, top=0.95, wspace=0.2, hspace=0.2)
ax0 = make_ax(fig, gs[:4, :4])
ax0.text(0.98, 0.98, "Random Initialization", transform=ax0.transAxes,
         ha='right', va='top', size=16)
draw_points(ax0, 'gray', factor=2)
draw_centers(ax0, centers, factor=2)

for i in range(3):
    ax1 = make_ax(fig, gs[:2, 4 + 2 * i:6 + 2 * i])
    ax2 = make_ax(fig, gs[2:, 5 + 2 * i:7 + 2 * i])

    # E-step
    y_pred = pairwise_distances_argmin(X, centers)
    draw_points(ax1, y_pred)
    draw_centers(ax1, centers)

    # M-step
    new_centers = np.array([X[y_pred == i].mean(0) for i in range(4)])
    draw_points(ax2, y_pred)
    draw_centers(ax2, centers, alpha=0.3)
    draw_centers(ax2, new_centers)
    for i in range(4):
        ax2.annotate('', new_centers[i], centers[i],
                     arrowprops=dict(arrowstyle='->', linewidth=1))


    # Finish iteration
    centers = new_centers
    ax1.text(0.95, 0.95, "E-Step", transform=ax1.transAxes, ha='right', va='top', size=14)
    ax2.text(0.95, 0.95, "M-Step", transform=ax2.transAxes, ha='right', va='top', size=14)


# Final E-step
y_pred = pairwise_distances_argmin(X, centers)
axf = make_ax(fig, gs[:4, -4:])
draw_points(axf, y_pred, factor=2)
draw_centers(axf, centers, factor=2)
axf.text(0.98, 0.98, "Final Clustering", transform=axf.transAxes,
         ha='right', va='top', size=16)


fig.savefig('figures/05.11-expectation-maximization.png')
png

Interactive K-Means

The following script uses IPython's interactive widgets to demonstrate the K-means algorithm interactively. Run this within the IPython notebook to explore the expectation maximization algorithm for computing K Means.
python
%matplotlib inline
import matplotlib.pyplot as plt
import seaborn; seaborn.set()  # for plot styling
import numpy as np

from ipywidgets import interact
from sklearn.metrics import pairwise_distances_argmin
from sklearn.datasets.samples_generator import make_blobs

def plot_kmeans_interactive(min_clusters=1, max_clusters=6):
    X, y = make_blobs(n_samples=300, centers=4,
                      random_state=0, cluster_std=0.60)

    def plot_points(X, labels, n_clusters):
        plt.scatter(X[:, 0], X[:, 1], c=labels, s=50, cmap='viridis',
                    vmin=0, vmax=n_clusters - 1);

    def plot_centers(centers):
        plt.scatter(centers[:, 0], centers[:, 1], marker='o',
                    c=np.arange(centers.shape[0]),
                    s=200, cmap='viridis')
        plt.scatter(centers[:, 0], centers[:, 1], marker='o',
                    c='black', s=50)


    def _kmeans_step(frame=0, n_clusters=4):
        rng = np.random.RandomState(2)
        labels = np.zeros(X.shape[0])
        centers = rng.randn(n_clusters, 2)

        nsteps = frame // 3

        for i in range(nsteps + 1):
            old_centers = centers
            if i < nsteps or frame % 3 > 0:
                labels = pairwise_distances_argmin(X, centers)

            if i < nsteps or frame % 3 > 1:
                centers = np.array([X[labels == j].mean(0)
                                    for j in range(n_clusters)])
                nans = np.isnan(centers)
                centers[nans] = old_centers[nans]

        # plot the data and cluster centers
        plot_points(X, labels, n_clusters)
        plot_centers(old_centers)

        # plot new centers if third frame
        if frame % 3 == 2:
            for i in range(n_clusters):
                plt.annotate('', centers[i], old_centers[i],
                             arrowprops=dict(arrowstyle='->', linewidth=1))
            plot_centers(centers)

        plt.xlim(-4, 4)
        plt.ylim(-2, 10)

        if frame % 3 == 1:
            plt.text(3.8, 9.5, "1. Reassign points to nearest centroid",
                     ha='right', va='top', size=14)
        elif frame % 3 == 2:
            plt.text(3.8, 9.5, "2. Update centroids to cluster means",
                     ha='right', va='top', size=14)

    return interact(_kmeans_step, frame=[0, 50],
                    n_clusters=[min_clusters, max_clusters])

plot_kmeans_interactive();
png

Gaussian Mixture Models

Covariance Type

python
from sklearn.mixture import GMM

from matplotlib.patches import Ellipse

def draw_ellipse(position, covariance, ax=None, **kwargs):
    """Draw an ellipse with a given position and covariance"""
    ax = ax or plt.gca()

    # Convert covariance to principal axes
    if covariance.shape == (2, 2):
        U, s, Vt = np.linalg.svd(covariance)
        angle = np.degrees(np.arctan2(U[1, 0], U[0, 0]))
        width, height = 2 * np.sqrt(s)
    else:
        angle = 0
        width, height = 2 * np.sqrt(covariance)

    # Draw the Ellipse
    for nsig in range(1, 4):
        ax.add_patch(Ellipse(position, nsig * width, nsig * height,
                             angle, **kwargs))

fig, ax = plt.subplots(1, 3, figsize=(14, 4), sharex=True, sharey=True)
fig.subplots_adjust(wspace=0.05)

rng = np.random.RandomState(5)
X = np.dot(rng.randn(500, 2), rng.randn(2, 2))

for i, cov_type in enumerate(['diag', 'spherical', 'full']):
    model = GMM(1, covariance_type=cov_type).fit(X)
    ax[i].axis('equal')
    ax[i].scatter(X[:, 0], X[:, 1], alpha=0.5)
    ax[i].set_xlim(-3, 3)
    ax[i].set_title('covariance_type="{0}"'.format(cov_type),
                    size=14, family='monospace')
    draw_ellipse(model.means_[0], model.covars_[0], ax[i], alpha=0.2)
    ax[i].xaxis.set_major_formatter(plt.NullFormatter())
    ax[i].yaxis.set_major_formatter(plt.NullFormatter())

fig.savefig('figures/05.12-covariance-type.png')

Discussion

コメントにはログインが必要です。
