04.06 Customizing Legends
Plot legends give meaning to a visualization, assigning meaning to the various plot elements.
We previously saw how to create a simple legend; here we'll take a look at customizing the placement and aesthetics of the legend in Matplotlib.
The simplest legend can be created with the
plt.legend() command, which automatically creates a legend for any labeled plot elements:
import matplotlib.pyplot as plt
plt.style.use('classic')%matplotlib inline
import numpy as npx = np.linspace(0, 10, 1000)
fig, ax = plt.subplots()
ax.plot(x, np.sin(x), '-b', label='Sine')
ax.plot(x, np.cos(x), '--r', label='Cosine')
ax.axis('equal')
leg = ax.legend();
But there are many ways we might want to customize such a legend.
For example, we can specify the location and turn off the frame:
ax.legend(loc='upper left', frameon=False)
fig
We can use the
ncol command to specify the number of columns in the legend:ax.legend(frameon=False, loc='lower center', ncol=2)
fig
We can use a rounded box (
fancybox) or add a shadow, change the transparency (alpha value) of the frame, or change the padding around the text:ax.legend(fancybox=True, framealpha=1, shadow=True, borderpad=1)
fig
For more information on available legend options, see the
plt.legend docstring.Choosing Elements for the Legend
As we have already seen, the legend includes all labeled elements by default.
If this is not what is desired, we can fine-tune which elements and labels appear in the legend by using the objects returned by plot commands.
The
plt.plot() command is able to create multiple lines at once, and returns a list of created line instances.
Passing any of these to plt.legend() will tell it which to identify, along with the labels we'd like to specify:y = np.sin(x[:, np.newaxis] + np.pi * np.arange(0, 2, 0.5))
lines = plt.plot(x, y)
# lines is a list of plt.Line2D instances
plt.legend(lines[:2], ['first', 'second']);
I generally find in practice that it is clearer to use the first method, applying labels to the plot elements you'd like to show on the legend:
plt.plot(x, y[:, 0], label='first')
plt.plot(x, y[:, 1], label='second')
plt.plot(x, y[:, 2:])
plt.legend(framealpha=1, frameon=True);
Notice that by default, the legend ignores all elements without a
label attribute set.Legend for Size of Points
Sometimes the legend defaults are not sufficient for the given visualization.
For example, perhaps you're be using the size of points to mark certain features of the data, and want to create a legend reflecting this.
Here is an example where we'll use the size of points to indicate populations of California cities.
We'd like a legend that specifies the scale of the sizes of the points, and we'll accomplish this by plotting some labeled data with no entries:
import pandas as pd
cities = pd.read_csv('data/california_cities.csv')
# Extract the data we're interested in
lat, lon = cities['latd'], cities['longd']
population, area = cities['population_total'], cities['area_total_km2']
# Scatter the points, using size and color but no label
plt.scatter(lon, lat, label=None,
c=np.log10(population), cmap='viridis',
s=area, linewidth=0, alpha=0.5)
plt.axis(aspect='equal')
plt.xlabel('longitude')
plt.ylabel('latitude')
plt.colorbar(label='log$_{10}$(population)')
plt.clim(3, 7)
# Here we create a legend:
# we'll plot empty lists with the desired size and label
for area in [100, 300, 500]:
plt.scatter([], [], c='k', alpha=0.3, s=area,
label=str(area) + ' km$^2$')
plt.legend(scatterpoints=1, frameon=False, labelspacing=1, title='City Area')
plt.title('California Cities: Area and Population');
The legend will always reference some object that is on the plot, so if we'd like to display a particular shape we need to plot it.
In this case, the objects we want (gray circles) are not on the plot, so we fake them by plotting empty lists.
Notice too that the legend only lists plot elements that have a label specified.
By plotting empty lists, we create labeled plot objects which are picked up by the legend, and now our legend tells us some useful information.
This strategy can be useful for creating more sophisticated visualizations.
Finally, note that for geographic data like this, it would be clearer if we could show state boundaries or other map-specific elements.
For this, an excellent choice of tool is Matplotlib's Basemap addon toolkit, which we'll explore in Geographic Data with Basemap.
Multiple Legends
Sometimes when designing a plot you'd like to add multiple legends to the same axes.
Unfortunately, Matplotlib does not make this easy: via the standard
legend interface, it is only possible to create a single legend for the entire plot.
If you try to create a second legend using plt.legend() or ax.legend(), it will simply override the first one.
We can work around this by creating a new legend artist from scratch, and then using the lower-level ax.add_artist() method to manually add the second artist to the plot:fig, ax = plt.subplots()
lines = []
styles = ['-', '--', '-.', ':']
x = np.linspace(0, 10, 1000)
for i in range(4):
lines += ax.plot(x, np.sin(x - i * np.pi / 2),
styles[i], color='black')
ax.axis('equal')
# specify the lines and labels of the first legend
ax.legend(lines[:2], ['line A', 'line B'],
loc='upper right', frameon=False)
# Create the second legend and add the artist manually.
from matplotlib.legend import Legend
leg = Legend(ax, lines[2:], ['line C', 'line D'],
loc='lower right', frameon=False)
ax.add_artist(leg);
